U-30 2K WB Satin Urethane Acrylic Hybrid - Pigmented
U-30 is a breakthrough technology combining urethane and acrylic characteristics to create a unique, zero-VOC water-based topcoat.
Overview
U-30 is a breakthrough technology combining urethane and acrylic characteristics to create a unique, zero-VOC water-based topcoat. By combining our hybrid urethane/acrylic resin with our proprietary aliphatic hardener blend we are able to create a high-solids, pigmented, satin finish that will not yellow, maintains its existing sheen and passes 2500 MEK double rubs! It is manufactured only in a satin sheen. If a gloss finish is desired, see the data sheet for U-20 2K WB Gloss Urethane.
Uses and Benefits
U-30 is primarily used as a pigmented topcoat due to its unsurpassed UV, mar and abrasion resistance. It can be applied to floors and walls and adheres well to many substrates including concrete, gypsum, cement board, metals, vinyl, PVC and fiberglass. It can also be applied direct to concrete as a primer and topcoat.
Limitations
U-30 is designed to be applied at 4-6 mils as a top coat on floors and walls. Allowing to puddle will have a negative effect on the finish. Ideal application temperatures to be between 60-90°F. Cooler temperatures and high humidity will increase cure times. Warmer temperatures and low humidity will decrease working and cure times. Verify that substrate temperature is 5 degrees above the dewpoint during application and cure of material to avoid a potential blush or condensation.
Preparation
The preparation method for each project is determined by a full understanding of the substrate to be coated, the chemistry of the coating system being used, the coating system thickness, and numerous other factors. The coating installer should fully read and understand ICRI Guideline NO. 310.2R-2013 and OSHA 29 CFR 1926.1153 before starting preparatory work. The aim, of preparing a substrate for coating applications, is to roughen the surface, remove weak layers, contaminants, dirt, debris and present a solid, clean, dry substrate for the primer. If unsure as to the level of preparation needed contact Polymer Nation at Lab@polymerNation.com.
Technical Data
At a glance — the specs most teams decide on.
- Shore Hardness @ 24 Hours
- 12Pendulum Hardness (Konig)
- Shore Hardness @ 7 Days
- 46Pendulum Hardness (Konig)
- Gloss @ 60° Angle
- 30-60
- VOCs of Mixed Material
- 0 g/lEPA Method 24
- Solids by Volume (Mixed)
- 58%
- Working Time
- 10-15 minutes
- Gel Time
- .75 Hours
- Dry to Touch
- 2-4 hoursWarmer temperatures will reduce time and colder temperatures will increase time. Higher RH will lengthen Dry time data
- Through Dry
- 6-10 hoursWarmer temperatures will reduce time and colder temperatures will increase time. Higher RH will lengthen Dry time data
- Dry to Walk
- 12-16 hoursWarmer temperatures will reduce time and colder temperatures will increase time. Higher RH will lengthen Dry time data
- Dry to Lightly Use
- 24 hoursWarmer temperatures will reduce time and colder temperatures will increase time. Higher RH will lengthen Dry time data
- Full Cure
- 7 daysWarmer temperatures will reduce time and colder temperatures will increase time. Higher RH will lengthen Dry time data
- Number of Components
- 2
- Mix Ratio (Liquids by Volume)
- 4:1It is always preferred to mix the entire kit, whenever possible, to avoid off-ratio mixtures
- Mixed Viscosity @ 25°C/77°F
- 250-500 cPWarmer temperatures will reduce viscosity and lower temperatures will increase viscosity
- Ideal Application Temperature
- 60-90°FVerify that substrate temperature is above 5 degrees of dew-point during application and cure of material to avoid a potential amine blush
- Application Thickness
- 4-6 mils
- Coverage Per Mix
- 275-400 sq.ft./gal.
- Odor
- None
- Storage Temperature
- 60-80 degrees FStore material between 60-90 degrees F in a protected dry location.
Colors & Packaging
Colors
White, Light Gray, Warm Sun
Packaging
- Available sizes
- 2.5 Gallons5 Gallons25 Gallons
- Note
- Special packaging is available based on size of order and time constraints
Where It's Used
Used in Systems
Mixing & Application
Combine all of part A and B into a single container, large enough to accept the entire kit. Mix at 350 RPM for 2-3 minutes using an appropriate mixing blade and making sure not to introduce excessive air into the solution (IF NEEDED, material can be thinned up to 10% with clean potable water).
Disposal: Dispose of material, containers, solvents, etc., per Federal, State and local guideline, rules and laws
