F-10 SL Pigmented Epoxy Slurry
F-10 SL combines our pigmented, nonylphenol-free, epoxy resin, our blended cycloaliphatic curing agent and our Slurry Aggregate PN 1360 to create an easy-to-use slurry material.
Overview
F-10 SL combines our pigmented, nonylphenol-free, epoxy resin, our blended cycloaliphatic curing agent and our Slurry Aggregate PN 1360 to create an easy-to-use slurry material. This mixture allows the installer to create a pigmented, high-build, epoxy flooring system in a shorter amount of time than double broadcasting the floor. The cured material has high compressive strength (three times that of concrete), great impact resistance and a broad range of resistance to chemical attack. It is virtually odor-free.
Uses and Benefits
F-10 SL is primarily used as a fast-setting epoxy overlay to protect and/or repair concrete when sloping is not required. On solid concrete, the system is self-priming and with the appropriate conditions and a skilled installer it can be left as a high-build, single step flooring system. When conditions or skill do not allow a one step process, a broadcast of select aggregates and fillers can be used to help level the floor and release trapped air.
Limitations
F-10 SL is designed to be applied at 1/8" (66 sq.ft./kit). Ideal application temperatures to be between 60-90°F. Cooler temperatures will increase cure times. Warmer temperatures will decrease working and cure times. Verify that substrate temperature is above 5 degrees of dewpoint during application and cure of material to avoid a potential amine blush.
Preparation
The preparation method for each project is determined by a full understanding of the substrate to be coated, the chemistry of the coating system being used, the coating system thickness, and numerous other factors. The coating installer should fully read and understand ICRI Guideline NO. 310.2R-2013 and OSHA 29 CFR 1926.1153 before starting preparatory work. The aim, of preparing a substrate for coating applications, is to roughen the surface, remove weak layers, contaminants, dirt, debris and present a solid, clean, dry substrate for the primer. If unsure as to the level of preparation needed contact Polymer Nation at Lab@polymerNation.com.
Key Benefits
- Inquire
Technical Data
At a glance — the specs most teams decide on.
- Shore Hardness @ 24 Hours
- 65Shore D
- Shore Hardness @ 7 Days
- 75-80Shore D
- Gloss @ 60° Angle
- 60-70Liquids only
- VOCs of Mixed Material
- <50 g/lEPA Method 24
- Color Scale per ASTM D1500
- 0.5-1.0Clear to slightly amber
- Solids by Volume (Mixed)
- 100%
- Working Time
- 25-35 minutes
- Gel Time
- 15 min.Warmer temperatures will decrease gel time and lower temperatures will increase gel time
- Dry to Touch
- 3-4 hoursWarmer temperatures will reduce time and colder temperatures will increase time
- Through Dry
- 4-6 hoursWarmer temperatures will reduce time and colder temperatures will increase time
- Dry to Walk
- 6 HoursWarmer temperatures will reduce time and colder temperatures will increase time
- Dry to Lightly Use
- 16-24 hoursWarmer temperatures will reduce time and colder temperatures will increase time
- Full Cure
- 5-7 daysWarmer temperatures will reduce time and colder temperatures will increase time
- Number of Components
- 3
- Mix Ratio (Liquids by Volume)
- 2:1 + 50 lb AggIt is always preferred to mix the entire kit, whenever possible, to avoid off-ratio mixtures
- Mixed Viscosity @ 25°C/77°F
- 300-400 cPLiquids only
- Ideal Application Temperature
- 60-90°FVerify that substrate temperature is above 5 degrees of dewpoint during application and cure of material to avoid a potential amine blush
- Application Thickness
- 1/8" (66 sq.ft./kit)1/8"
- Coverage Per Mix
- 66 sq.ft./kit
- Odor
- Subtle
- Storage Temperature
- 60-80 degrees FStore material between 60-90 degrees F in a protected dry location.
- Number of Mixes per Kit
- 1
Colors & Packaging
Colors
Tap a color to enlarge. Swatches are a representative guide — request a physical sample for color-critical work.
Packaging
- Available sizes
- 3 Gallons + 50 lbs. Aggregate
Where It's Used
Markets
Used in Systems
Mixing & Application
A mixture consists of 2 gallon F-10 SL Part A, 1 gallon F-10 SL Part B and 50 LB. of C (PN 1360). Combine part A and B into a single container, large enough to accept the entire kit (1 mix equals 6.5 gallons when Part C is added). Premix liquids at 350 RPM for 1 minutes using an appropriate mixing blade or mixing machine. Pour Part C into the mixed resin and continue mixing until a homogenous mortar is achieved (2-3 minutes usually), making sure not to introduce excessive air into the solution.
Disposal: Dispose of material, containers, solvents, etc., per Federal, State and local guideline, rules and laws
More Miscellaneous
Related products
Complete the system or compare close alternatives in the same family.
Made in the USA · Tech Support Included
Need F-10 SL for your project?
Our team will help you spec the right system, quantities, and colors — and get you a quote fast.
