Durable, low-odor urethane concrete for industrial cove bases. Offers high impact and thermal shock resistance with extended working time.

W-52 CK

About the product

W-52 CK Urethane Concrete Cove Base is a high-performance 3-part system formulated for industrial coving. It utilizes a water-based urethane resin and aromatic hardener combined with Portland cement, lime, and proprietary fillers. This composition delivers best-in-class impact and thermal shock resistance with very low VOC content (<50 g/L), minimal odor, and ease of application. It can be applied to green concrete and formed to 1/8”–1/4” thickness in a single pass using a cove trowel.

The system includes Part A (44.5 oz), Part B (32 oz), and Part C (30 lbs), pre-measured for efficient mixing. With a working time of 15–20 minutes and dry-to-light-use time of 16–24 hours, it minimizes downtime while delivering Shore D hardness of 78 after 7 days. It’s ideal for manufacturing, food processing, and other environments requiring hygienic and durable transitions.

W-52 CK can be applied over SP-71 or SP-81 primers while tacky. C-99 is recommended as a trowel lubricant. Coverage is approximately 32 linear feet per mix when forming a 4” cove with 1” radius. Colors include Natural, Tile Red, Light Gray, Medium Gray, Dark Gray, Black, and Tan. The system is self-extinguishing (ASTM D635), highly abrasion-resistant (0.029g loss per ASTM D4060), and delivers excellent adhesion to concrete (>450 psi).

Product Details

For the most up-to-date product details, please view the Product Spec PDF below

PRODUCT PDF

Name

W-52 CK

Category

Patching, Joint, Cove

Kit Yield in Gallons

1.05 gal. A; 0.75 gal. B; 3 – 30 lb. Bags

Number of Mixes Per Kit

Three-mix Kit

Number of Components

3

Mix Ratio Liquids by Volume

Part A - 44.5oz

Part B - 32 oz.

Part C - 30 lbs.

Ideal Application Temperatures

60°F to 90°F (15.5°C to 32°C)

Mixed Viscosity in cP@25C/77F

300 cP

Measured for Parts A & B combined before the aggregate is added.

Gel Time

Dry to Touch

2–3 hours

Tested at 72–75°F and 30–50% RH. Actual time may vary based on temperature and humidity.

Through Dry

4–8 hours

Dry time will be shorter in warmer temperatures and longer in cooler environments.

Dry to Walk

Dry to Lightly Use

16–24 hours

Tested at 72–75°F and 30–50% relative humidity. Cooler temps may extend this time.

Full Cure

7 days

Achieves full mechanical and chemical performance at 7 days under standard test conditions.

Shore Hardness at 24 Hours

D70

Measured under ASTM D2240 after curing at room temperature (72–75°F).

Shore Hardness at 7 Days

D78

Indicates full hardness achieved by day 7 in standard conditions.

Gloss @ 60 Degree Angle

30–50

Measured on cured surface using standard glossmeter under ASTM D523.

VOC’s of Mixed Material

<50 g/L

Measured by EPA Method 24. Near zero VOC content.

Color Scale per ASTM D1500

0.5–1.0

Indicates very light color variation; measured for consistency.

Solids by Volume Mixed

>99%

Extremely high solids content, minimizing shrinkage and maximizing durability.

Storage

60–80°F

Store in a dry, protected location. Avoid freezing and exposure to moisture.

Odor

Low

Low-odor formulation suitable for indoor and occupied environments.

Application Thickness in Mils

125–250 mils

Applies between 1/8" and 1/4" thickness per pass, depending on project requirements.

Coverage Per Mix

32 linear feet (4” cove with 1” radius)

Disposal

Dispose of material, containers, and solvents according to federal, state, and local regulations.

Available Colors

Natural, Tile Red, Light Gray, Medium Gray, Dark Gray, Black, Tan

Standard color range. Custom colors may be available upon request.

Mixing & Installation

Mix Part A (44.5 oz) and Part B (32 oz) for 15–30 seconds. Add one 30 lb bag of Part C and mix 2–3 minutes until homogeneous. Use within 10–15 minutes. Apply with a margin trowel and finish with a cove trowel. Use C-99 as a trowel lubricant. Recoat within 24 hours.

Other Product Names

Polymer Nation believes the information contained herein to be true and accurate. Information contained herein is for evaluation purposes only.
